Enlarge SC/PC-SC/PC 10G /OM3 patch cord

SC/PC-SC/PC 10G /OM3 patch cord

Payment Terms: T/T,L/C
Place of Origin: Hebei, China (Mainland)
inquire
Add to My Favorites
HiSupplier Escrow
Share |

Product Detail

Means of Transport: Ocean,Land,Air

1, optical fiber communication system,
2, optical fiber data transmission;
3, a local area network (LAN),
4, optical fiber sensors,
5, CATV.

 Applicable scope:
1, optical fiber communication system,
2, optical fiber data transmission;
3, a local area network (LAN),
4, optical fiber sensors,
5, CATV.
Parameters
Insertion loss
Single mode
PC≤0.3dB
UPC≤0.2dB
APC ≤0.3dB
Multimode
PC≤0.5dB
UPC≤0.3dB
APC ≤0.3dB
Return loss
PC≥48dB
UPC≥50dB
APC ≥60dB
Multimode
PC≥25dB
UPC≥45dB
APC ≥50dB
Repeatability
≤0.1db
Changeability
≤0.2dB
Working temperature
-40 to +80℃
Durability
1000 times
Sustain tension
≥100N
9/125um ,50/125um, 62.5/125um, etc.
Diameter
0.9mm 2.0mm 3.0mm, etc.
Cable material
PVC, LSZH
